Atlantis
Solar Monocrystalline Silicon
Photovoltaic Solar Panel Technical
Specifications: |
Home |
|
| |
|
Model |
Dimensions frame |
Maximum power |
Optimum operating
voltage |
Optimum operating
current |
Open-circuit voltage |
Short-circuit
current |
Cell in need |
Weight |
FF(%) |
| |
(mm*mm*mm) |
Max (W) |
Vmp (V) |
Imp (A) |
Voc (V) |
Isc (A) |
W |
KG |
Time filling factor |
|
AS-MSP230M |
1954*996*50 |
230 |
35.6 |
6.38 |
39.6 |
7.02 |
3.2 |
19 |
70.20% |
|
AS-MSP220M |
1638*996*50 |
220 |
29.6 |
7.33 |
32.8 |
8.06 |
3.66 |
19 |
70.20% |
|
AS-MSP210M |
1638*996*50 |
210 |
29.6 |
3.5 |
32.7 |
3.85 |
3.5 |
19 |
70% |
|
AS-MSP200M |
1638*996*50 |
200 |
26.8 |
7.4 |
29.7 |
8.15 |
3.7 |
19 |
69.80% |
|
AS-MSP180M |
1480*996*35 |
180 |
26.8 |
6.66 |
29.7 |
7.33 |
3.33 |
18 |
70.20% |
|
AS-MSP170M |
1480*996*35 |
170 |
26.6 |
6.3 |
29.6 |
6.92 |
3.15 |
18 |
70.10% |
|
AS-MSP165M |
1480*996*35 |
165 |
35.4 |
4.74 |
39.2 |
5.05 |
2.3 |
18 |
70% |
|
AS-MSP160M |
1480*996*35 |
160 |
35.2 |
4.65 |
39.4 |
5 |
2.23 |
18 |
69.80% |
|
AS-MSP150M |
1480*996*35 |
150 |
35.4 |
4.58 |
39.2 |
5 |
2.1 |
18 |
69.80% |
|
AS-MSP140M |
1328*810*35 |
140 |
29.8 |
4.66 |
32.8 |
5.13 |
2.33 |
16 |
69.60% |
|
AS-MSP130M |
1328*810*35 |
130 |
29.6 |
4.33 |
32.7 |
4.76 |
2.17 |
16 |
69.40% |
|
AS-MSP120M |
1200*810*35 |
120 |
26.8 |
4.44 |
29.7 |
4.88 |
2.22 |
16 |
69.40% |
|
AS-MSP110M |
1200*810*35 |
110 |
26.8 |
4.07 |
29.7 |
4.48 |
2.05 |
16 |
69.40% |
|
AS-MSP080M |
1205*561*50 |
80 |
17.2 |
4.75 |
21.6 |
5 |
2.2-2.3 |
9 |
70.20% |
|
AS-MSP081M |
1205*561*50 |
75 |
17.2 |
4.75 |
21.6 |
5 |
2.2 |
9 |
70% |
|
AS-MSP070M |
1205*561*50 |
70 |
17.2 |
4.65 |
21.2 |
4.8 |
1.9-2 |
9 |
70% |
|
AS-MSP050M |
830*561*35 |
50 |
17.6 |
3.1 |
17.3 |
3.3 |
1.3-4 |
8 |
69.80% |
|
AS-MSP040M |
643*561*35 |
40 |
17.4 |
2.4 |
17.2 |
2.5 |
1.1-1.2 |
7 |
69.80% |
|
AS-MSP030M |
584*435*25 |
30 |
17.2 |
1.5 |
17.3 |
1.7 |
0.8-0.9 |
6 |
69.60% |
|
AS-MSP020M |
459*435*25 |
20 |
17.3 |
1.1 |
17.1 |
1.23 |
0.5-0.6 |
5 |
69.60% |
|
AS-MSP010M |
359*312*25 |
10 |
17.2 |
0.57 |
17.2 |
0.62 |
0.27-0.3 |
4 |
69.60% |
|
| |
 |
| |
 |
| |
| Standard
Test Conditions |
|
AM |
1.5 |
|
Irradiation |
1000 |
W/m2 |
|
Tc |
25 |
șC |
|
| |
| Mechanical
Characteristics |
|
Weight (kg) |
16kg |
|
Frame Structure (Material Corners) |
Aluminum Anodized |
|
Front Side |
Glass |
|
Front Glass Thickness |
3.2 mm |
|
Encapsulant |
EVA |
|
Back Side |
TPT |
|
Junction Box |
IP65 |
|
Bypass Diode |
Three 10amp |
|
Series Fuse Rating |
10A |
|
|
| |
| Packing
and Transport |
|
Packing Configuration |
10 Pcs per carton |
|
Size of Carton |
1630x550x900 mm |
|
Weight of Carton |
9 kg |
|
Cartons per 20' Container |
24 Cartons |
|
Cartons per 40' Container |
56 Cartons |
|
| |
| Absolute
Maximum Ratings |
|
Operating Temperature |
-40șC
~ +90șC șC |
|
Storage Temperature |
-40șC
~ +90șC șC |
|
Maximum Load Capacity |
200 |
Kg/m2 |
|
Maximum Hail Diameter @ 80Km/h |
25mm |
@80Km/h |
|
| |
|
